| Model | ES-5.12L |
| Total Energy [kWh] | 5.12 |
| Capacity [Ah] | 200 |
| Nominal Voltage [V] | 25.6 |
| Voltage Range [M] | 24-28.8V |
| MAX.Charge & Discharge Current[A] | 80 |
| Dimension[W×DxH,mm] | 220×270×550 |
| Net Weight [Kg] | 33.5KG |
Introduction
24V 200ah LiFePO4 Battery
95% DOD with More Usable Capacity
Long cycle life：More than 6000 Cycles
Compatible with most of available solar inverters
Support CAN&RS485 Communication
Equipped Smart BMS
Warranty：5 Years
Wall mounted lithium battery is mainly for home energy stoarge solutions
| Model | ES-5.12L | ES-10.24L | ES-15.36L | ES-17.92L |
| Total Energy [kWh] | 5.12 | 10.24 | 15.36 | 17.92 |
| Capacity [Ah] | 200 | 200 | 300 | 350 |
| Nominal Voltage [V] | 25.6 | 51.2 | 51.2 | 51.2 |
| Voltage Range [V] | 21-28.8 | 48-57.6 | 48-57.6 | 48-57.6 |
| MAX. Charge & Discharge Current [A] | 50 | 80 | 120 | 150 |
| Peak Charge & Discharge Current [A] (for 10 sec.) | 80 | 120 | 150 | 200 |
| Dimension [W x D x H, mm] | 220*270*550 | 610×160×800 | 577*680*280 | 721*680*280 |
| Net Weight [Kg] | 34 | 72 | 110 | 135 |
| Scalable | 1~16 in parallel | |||
| Communication | CAN,RS485 | |||
| Communicated Inverter | GOODWE / Victron / SOFAR / Deye / Growatt / Solis / SMA / SRNE | |||
| Enclosure Protection Rating | IP21 | |||
| Working Temperature Range [℃] | -10 ~ 50 | |||
| Cycle Life | ＞6,000 Cycle@ 80% DOD / 25℃ / 0.5C, 60%EOL | |||
| Warranty | 5 years | |||
| Certification | IEC62619,UN38.3,CE | |||
